SureColor P20560 - 64"

64" Production Photo, Fine Art and Signage Printer

64" PHOTOGRAPHY & FINE ART PRINTER
PRODUCT NAME SureColor P20560 - 64"
SIZE
Max Print Width 64 inch (1,626mm) wide
Max Sheet Size Super B0+
PRINT TECHNOLOGY
Print Head PrecisionCore™ Micro TFP head
Print Modes Uni & Bi-directional
Print Technology VSDT, auto head alignment, auto/manual nozzle checking, auto cleaning, ink repelling coating
Nozzle Configuration 800 per colour
Channels 12
Max Resolution 2400 x 1200 dpi
Min Droplet Size 3.5 pl
INK SYSTEM
Family Ultrachrome® Pro12
Type Aqueous all-pigment
Colours 12
Pouch Size 1.6 L
PERFORMANCE
Speed 300 x 600 dpi          25.00 m2/hr
Quality 600 x 600 dpi          18.18 m2/hr
High Quality 1200 x 600 dpi      10.46 m2/hr
Max Quality 2400 x 1200 dpi      5.60 m2/hr
test pattern Figures represent print times for the test sample image shown, produced on 60” Epson Premium Lustre Paper (260 gsm), resized to a square metre, and printed in landscape orientation. The tested print speeds were measured from the initiation of head movement and ink delivery to the completion of ink delivery and the start of internal cutting. Results may vary on alternative media types. Additional processing time may be required, and individual results may vary depending on print mode, software, operating environment, media, and data file size/type.
MEDIA SUPPORT
Format Roll and cut sheet
Size Roll: Width 254 (min) to 1626 mm (max) Length 279 to 15,000 mm, Diameter 170 mm (max) Max weight 24 kg
Cut sheets: Width 210 (min) to 1118 mm (max) Length 279 (min) to 1580 mm (max)
Thickness 0.08 - 0.5 mm roll / 0.08 - 1.5 mm sheet
Min Margins 0 mm top, left, right & bottom roll / 3 mm top, 0 mm left & right, 14 mm bottom sheet
Loading Top manual sheet and top roll (spindle-less)
Handling Heavy-duty rotary auto-cutter & Media Barcode System
Output Front manual paper basket (able to hold one B0+ print with a maximum length of approx. 1,580 mm) and optional auto take-up unit
Manual Double Sided Printing Please refer to user guide, and contact Epson or your authorised dealer before selecting any media for this purpose in order to check suitability.
OPERATION
Control Panel 4.3" colour touchscreen LCD
Interface High-speed USB 3.0
Ethernet 100Base-TX / 1000Base-T
Included Software Epson Edge Print PRO
Web Downloads (Windows) Printer Driver, Epson Manual, Installer Package, Web Installer, EpsonNet Setup Manager, EpsonNet Print, EpsonNet Config, Epson Print Layout, Epson Edge Dashboard, Epson Media Installer, Epson Device Admin, Epson Edge Color, Epson Print Automate, Epson Network Utilities, Software and Firmware Updater, Epson Cloud Solution PORT
Web Downloads (Mac) Printer Driver, Epson Manual, Installer Package, Web Installer, EpsonNet Print, EpsonNet Config, Epson Print Layout, Epson Edge Dashboard, Epson Network Utilities, Software and Firmware Updater, Epson Cloud Solution PORT
OS Compatibility Mac OS X10.9.5 or later, Windows 7/8/8.1 (32-bit/64-bit) or later
Software Compatibility Compatible with a wide range of design, production, workflow management and RIP software
Memory 6 GB
Language ESC/P Raster
ENVIRONMENT
Operational Temp 10° - 35° C (15 - 25° C recommended)
Operational Humidity 20 - 80% with no condensation (40 - 60% recommended)
Power Supply 100 - 240 V, 50 Hz - 60 Hz AC, 5 A
Power Consumption 95 W operating / 2.2 W sleep (1000 Base-T)
Operating Noise 55 db
PHYSICAL
Printer (W x D x H) 2740 x 760 x 1145 mm, 224 kg (no ink or media)
Recommended Operational Space 2.6 x 1.6 x 1.3 m (W x D x H)
Packaging (W x D x H) Printer & Stand: 2791 x 989 x 1077 mm, 320 kg
(Important: Box must be shipped straight & level)
Bulk ink solution: 606 x 794 x 965 mm, 57 kg
WHAT'S IN THE BOX
Printer, stand, paper basket, roll rests, AC power cable, 2 x roll adapter, setup guide, 3 x maintenance box, dust cover, cleaning stick, cleaning sheet, cleaning sheet, ink guard, hex wrenches (L×1, S×1), Epson Edge Print Pro, bulk ink solution (in a separate box) and set of 1.6 L inks (in a separate box)
CONFIGURATION OPTIONS
SCP205601YR Printer with 1-year onsite warranty
SCP205603YR Printer with 2-year CoverPlus onsite service pack (total 3 yrs cover)
SCP205605YR Printer with 4-year CoverPlus onsite service packs (total 5 yrs cover)
ACCESSORIES & OPTIONS
C12C932201 Auto take-up unit
C12C932231 Additional roll adaptor
C13S210040 Replacement auto cutter blade
C13T619300 Replacement maintenance tank
C12C939191 Postscript module
C12C936671 960 GB SSD
YR2P20560 Year 2 onsite CoverPlus
YR3P20560 Year 3 onsite CoverPlus
YR4P20560 Year 4 onsite CoverPlus
YR5P20560 Year 5 onsite CoverPlus
SERVICE & SUPPORT
The printer and any associated options purchased with it are supplied with a 1-year onsite warranty that covers parts and labour including the printhead. The printer may be ordered with additional CoverPlus for a total maximum cover of up to 5 years.

Limitations apply to the provision of warranty and CoverPlus (see below). Support is only provided for product supplied through Epson Australia or Epson New Zealand. The facility is provided in conjunction with the authorised large format reseller through which the product is ordered and Epson's network of authorised service partners. Service will be provided onsite at no charge for equipment located in major metropolitan areas with ready access. Regional locations and installations with difficult access may receive onsite service subject to imposition of a travelling/access charge.


IMPORTANT NOTES
Epson Cloud Solution PORT is a secure cloud-based service that is used to facilitate the provision of support on this model. Agreement to the terms of supply and registration under the program is required to enable fulfilment of CoverPlus. During operation, the printer must remain connected to a network with Internet access via a router configured for two-way data transfer.

This model supports user self-replacement of the printhead. Operation requires Epson Cloud Solution PORT and nomination of one or more staff members to perform the process. Staff should have a moderate level of technical skill and must undertake training (can generally be performed during the installation process). In the event that the nominated staff member leaves employment, a replacement will need to be nominated and undertake training (may attract additional charges).

Service may be restricted or limited if equipment is not installed in an appropriate environment, not appropriately maintained, be modified, used outside of specification, with non-Epson consumables or without activation of Epson Cloud Solution PORT. For further details on cover, terms and conditions please review the warranty terms and CoverPlus sections of this web-site. If you have additional questions, please contact Epson directly.
Usage Conditions
Epson products are designed and made to give highly reliable use and long life when used according to its specifications. With any system, product or device used in situations where human life may be involved or at risk, Epson advises that you should take all necessary steps to ensure the suitability of your Epson product for inclusion in your system, and recommends that you include fail-safe procedures and redundancy support or backup equipment in your system, to maintain the maximum safety margin and optimum system reliability. Examples include but are not limited to – do not interfere with any electrical components within the device, do not use items supplied with the product for purposes other than as intended by Epson (ie mains cords, inks, CDs, plastic wrapping) and do not make modifications to the product.
