SureColor P5070 - 17"
17" Production Photo, Proofing & Packaging Printer
| A2+ PHOTOGRAPHY & FINE ART PRINTER | |
|---|---|
| PRODUCT NAME | SureColor P5070 - 17" |
| SIZE | |
|---|---|
| Max Print Width | 17 inch (432mm) |
| Max Sheet Size | A2+ |
| PRINT TECHNOLOGY | |
|---|---|
| Print Head | PrecisionCore® TFP |
| Print Modes | Uni & Bi-directional |
| Features | Variable Sized Droplet Technology (VSDT) Advanced Epson LUT Enhanced Colour Density & Gamut Enhanced Print Durability |
| Active Channels | 10 (Auto Pk / Mk switching) |
| Max Resolution | 2880 x 1440 dpi |
| Min Droplet Size | 3.5 pl |
| INK SYSTEM | |
|---|---|
| Family | Epson Ultrachrome® HDX |
| Type | Aqueous all-pigment |
| Colours | 11 (Configurable with Light Light Black OR Violet)* |
| Cartridge Size | 200 ml |
| PERFORMANCE (A2 sheet) | |
|---|---|
| Draft | 360 x 360 dpi 0.5 minutes |
| Normal | 360 x 720 dpi 0.8 minutes |
| Fine | 720 x 720 dpi 1.8 minutes |
| Super Fine | 720 x 1440 dpi 3.6 minutes |
| Super Photo | 2880 x 1440dpi 7 minutes |
 Figures represent print times only for the test sample image as shown, produced on Plain paper (Draft – Fine modes) and Premium Photo paper (Super Fine & Super Photo modes). The total throughput time for a particular image will depend on a number of factors including the PC, software application, workflow configuration, networking, file format / size, image content, paper type and print mode. |
|
| MEDIA SUPPORT | |
|---|---|
| Format | Cut sheet and Roll |
| Size | 8" x 10" (203 x 254mm) - A2+ (432 x 610mm) sheets 203-432mm wide x 150mm diameter 3" core / 103mm diameter 2" core rolls |
| Thickness | 0.08-1.5mm sheets 0.08-0.5mm rolls |
| Min Margins (Normal Printing) | 3mm top, 0mm left & right, 14mm bottom sheets 0mm top, left, right & bottom rolls |
| Borderless Printing (Supported on nominated widths only) | Roll media: 210mm, 297mm, 8" (203.2mm)*, 10" (254mm), 11" (279.4mm)*, 300mm, 329mm, 16" (406.4mm), 420mm*, 17" (431.8mm) Cut Sheets: A4, A3, A3+, 10" (254mm), 300mm, 16" (406.4mm), 17" (431.8mm) * Requires a 2" core and use of the borderless print spacer supplied with the printer |
| Max Print Length | 15m |
| Loading | Front & rear manual, top tray & front cassette (up to 250 plain & 100 photo) sheets Top roll (spindle style with dual tension settings) |
| Roll Handling | Heavy-duty rotary auto-cutter (under 5s per page) Media Barcode System for roll management |
| Output | Front with extendable tray |
| Double Sided Printing | Supported via manual loading however please refer to the user guide, and contact Epson or your authorised dealer before selecting any media for this purpose in order to check suitability. |
| OPERATION | |
|---|---|
| Control Panel | 2.7” Colour LCD |
| Interface | High Speed USB 2.0 Ethernet 10Base-T / 100Base-TX / 1000Base-T |
| Included Software (Windows) | Printer Driver, LFP RemotePanel 2, EpsonNet Setup, EpsonNet Config, EpsonNet Print, Epson Color Calibration Utility, Installer Package, User Guide, Manual Launcher, Software Updater |
| Web Downloads (Windows) | Epson Print Layout, CopyFactory, EpsonNet Setup Manager, Firmware Updater |
| Included Software (Mac) | Installer Package, Epson Color Calibration Utility |
| Web Downloads (Mac) | Epson Print Layout, Printer Driver, User Guide, Manual Launcher, Software Updater, EpsonNet Setup, Firmware Updater & Software Uninstaller |
| OS Compatibility | Mac OS X 10.6.8 or later Windows 10, 8/8.1, 7, Vista, & Win XP SP1 |
| ARM 64 Processor Compatibility | IMPORTANT NOTICE: A number of printer drivers have been found to have compatibility issues with Windows PCs that feature an ARM 64 processor. Epson is currently reviewing our current and recent model ranges with a view to issuing updates. Unfortunately, although we will roll these out as quickly as we can the process is not expected to be completed until early 2026. In the interim we do not recommend operation with this type of equipment. |
| 3rd Party S/W Compatibility | Compatible with a wide range of design, production, workflow management, and RIP software |
| Memory | 256MB Main and 128MB Network |
| Language | ESC/P Raster |
| ENVIRONMENT | |
|---|---|
| Operational Temp | 10° to 35° C (15-25° C recommended) |
| Operational Humidity | 20 to 80% with no condensation (40-60% recommended) |
| Power Supply | 100 - 240 V, 50 Hz - 60 Hz AC, 2A |
| Power Consumption | 52W Operating / Standby 20W / 5W Sleep (1000BASE-T) |
| Operating Noise | 47 dB |
| Operational Space (W x D x H) |
1163 x 1349 x 586mm recommended (Additional space will be required at rear when using the straight through paper path) |
| PHYSICAL | |
|---|---|
| Dimensions (W x D x H) | 863 x 766 x 405 mm (Sheet feed & output tray closed) |
| Weight | 52Kg (no ink) 60Kg (as above with Spectro mounted) |
| WHAT'S IN THE BOX | |
|---|---|
| Printer, Power Cord, Set of 80ml Inks (20-50% of each loaded cart will be used to charge the machine during initialisation and the unused LLK OR Violet cart must be discarded), 1 x Roll Media Adaptor Set, 1 x Maintenance Tanks, 1 x Borderless Maintenance Tank, Installation / Safety manual, Utility software & User manual (CD). Configurations include an additional SpectroProofer and mounting kit. | |
| Packaging (W x D x H) |
Printer: 905 x 577 x 1007mm, 65 Kg Spectro: 135 x 260 x 105 mm, 0.5 Kg Spectro Mount: 382 x 400 x 809, 12 Kg |
| CONFIGURATION OPTIONS | |
|---|---|
| SCP5070SP1YR | Printer + SpectroProofer ILS30 with 1 Year On-site Warranty** |
| SCP5070SP3YR | Printer + SpectroProofer ILS30 with 3 Yr On-Site CoverPlus** |
| SCP5070SP5YR | Printer + SpectroProofer ILS30 with 5Yr On-Site CoverPlus** |
| ACCESSORIES & OPTIONS | |
|---|---|
| C12C890121 | Roll Paper Belt |
| C13T619000 | Replacement Maintenance Tank |
| C12C815351 | Replacement Auto Cutter Blade |
| C13T619100 | Replacement Borderless Maintenance Tank |
| C12C811251 | Additional/Replacement Dual Tension Roll-Feed Spindle |
| C13S400045 | Cleaning Sheet Pack |
| YR2P5070SP | Yr 2 On-Site CoverPlus** - P5070 & Spectro |
| YR3P5070SP | Yr 3 On-Site CoverPlus** - P5070 & Spectro |
| YR4P5070SP | Yr 4 On-Site CoverPlus** - P5070 & Spectro |
| YR5P5070SP | Yr 5 On-Site CoverPlus** - P5070 & Spectro |
| ** The printer comes with a comprehensive warranty that includes cover for the Print Head. The SpectroProofer also comes with a 12 month replacement warranty. Optional CoverPlus packages enable cover to be extended with an enhanced service level. CoverPlus can be purchased concurrently with the printer or ordered separately up to 365 days after the original product invoice date. Cover can be extended by 1, 2, 3 or 4 years (total cover cannot exceed 5 years). Limitations apply to the provision of Warranty and CoverPlus Service. Support is only provided for product supplied through Epson Australia or Epson New Zealand. The facility is provided in conjunction with the Authorised Large Format Reseller through which the product is ordered. Regional locations and installations with difficult access may attract additional charges. Service may be restricted or limited when equipment is modified, used outside of specification, &/or with non-Epson consumables. For full details on coverage, terms and limitations please review the warranty terms listed on this web-site and contact Epson or one of our Authorised Large Format Resellers if you have questions or concerns. |
|
| Usage Conditions | |
|---|---|
| Epson products are designed and made to give highly reliable use and long life when used according to its specifications. With any system, product or device used in situations where human life may be involved or at risk, Epson advises that you should take all necessary steps to ensure the suitability of your Epson product for inclusion in your system, and recommends that you include fail-safe procedures and redundancy support or backup equipment in your system, to maintain the maximum safety margin and optimum system reliability. Examples include but are not limited to – do not interfere with any electrical components within the device, do not use items supplied with the product for purposes other than as intended by Epson (ie mains cords, inks, CDs, plastic wrapping) and do not make modifications to the product. |
- At time of installation the end user needs to choose to configure the machine with either Light Light Black or Violet ink. Once this choice has been made it is final and cannot be undone or switched at a later time.
