SureColor R5000L - 64" RESIN

64" High-Production Signage & Décor Printer

RESIN - SIGNAGE PRINTER
PRODUCT NAME SureColor R5000L - 64" RESIN
SIZE
Max Media Width 64 inch
PRINT TECHNOLOGY
Print Head Dual Epson 2.6" PrecisionCore Micro TFP
Print Operation Epson Precision Dot with Multi-layer Half Tone
Variable Sized Droplet Technology (VSDT)
User Adjustable Optimiser Application
Advanced Airflow and Dust Management
Ink-less Nozzle Status Monitoring
Auto Nozzle Masking/Replacement
Self-cleaning Print Heads
Self-cleaning Cap and Flushing Systems
Dual Re-usable 4L Waste Tanks
Print Modes Uni & Bi-directional
Nozzle Configuration 400 nozzles x 12 lines x 2Heads
Maximum resolution 1200 x 2400dpi (8 x 600 x 600dpi Halftone Layers)
Minimum Ink Droplet Size 4.9pl
INK TECHNOLOGY
Ink Type Low Odour, Nickel Free, Pigment-based Resin with Reduced Curing Temperature and Enhanced Scratch Resistance
Certification Ecologo, HAPs Free, Reach and Nordic Swan
Ink Family Epson UltraChrome® RS
Colours 6c (CMYKLcLm) + Optimiser + Maintenance Liquid
Storage R5000L: Dual 8 x 1.5L CISS with auto hot-swap
Waste System 4L reusable tank
PERFORMANCE
Max Speed 116.5m²/hr (600 x 300dpi 1 pass)
Banner Fast Production 27.3m²/hr (600 x 1200dpi 5 pass)
Banner Production
Vinyl, Paper & Wall covering Fast Production		 21.0m²/hr (600 x 1200dpi 6 pass)
Vinyl, Paper & Wall covering Production 15.1m²/hr (1200 x 1200dpi 9 pass)
Textile Production 9.5m²/hr (1200 x 1200dpi 14 pass)
Film Production 5.2m²/hr (1200 x 2400dpi 26 pass)
Print Sample Figures are based on print speed only for the nominated image produced 1613.3x2016.6mm using Epson Edge Print. They do not include provision for image processing time or transmission. Not all print modes are supported by all media and /or RIP software; individual results are subject to variation due to a variety of configuration, operational, and image specific factors.
MEDIA SUPPORT
Loading Single Roll, 2”/ 3” core, 250mm max outer diameter and 45kg max weight
Size 530 to 1626mm wide, 1mm max thickness
Minimum Print Margins 3 mm left & right (5mm with Edge Guides)
Heater Settings 30° ~ 55° C Pre Platen
30° ~ 50° C Platen
40° ~ 110° C Curing/Drying
Handling Media Pre-sets
EMX Media and Print Profile Management
Ultra-sonic Media Status and Media Jam Monitoring
High Precision Multi-Stage and Multi-Element Media Heating/Drying
Precision Feed Management with Advanced Auto Tension Control (Ad-ATC)
Output Format Single sheet (manual cut)
Roll (integrated ATU supports 2" / 3" core with 200mm max outer diameter)
Application Certification Greenguard, Frenc-VOC, AgBB, EN71-3 and GS
OPERATION
Control Panel 4.3” Colour Touch LCD
Status/Warning Industrial Style Signal Lamp, see-through Platen Cover with Integrated Lighting, Advanced Web-Based Monitoring & Email Status Notification
Interface High Speed USB 2.0, & Ethernet 100Base-TX/1000Base-T
Memory 2GB
Power Supply 200-240V 16A, 50-60 Hz AC
Printer Physical 2,949 x 1,605 x 1,045 mm (WxHxD)
R5000L: 447Kg (inc. CISS, no ink or media)
Control & Utility Software Epson Edge Dashboard, Epson LFP Accounting Tool, Epson Communication Driver, Installer Package, Epson Manuals Launcher, Epson NetConfig, Epson NetSetup, Epson NetPrint, Epson Software Updater, Epson Cloud Solution PORT.
RIP Software Supplied with Epson Edge Print
Also supports a wide range of 3rd party applications
OS Support Win 7 64bit or later
Mac OS X 10.7 or later (only applications marked with * are compatible)
Operational Temp 15° to 30° C (20-25° C recommended)
Operational Humidity 20 to 80% (40 - 60% recommended)
Typical Energy Use 4.6kW Operating / 220W Ready / 44W Sleep
Operating Noise 66.1dB
Operational Space 3.6 x 1.8 x 2.7m (WxHxD) recommended
WHAT'S IN THE BOX
Printer with Dryer, Media Supply System (with Stand, Feed and Auto Take-Up), CISS unit, 1 x user maintenance kit, 2 x waste tanks, 1 x ink set (R5000L: 16 x 1.5L pouches), 2 x Media Edge Guides, Media Cleaning Brush, 1 x Thermal Sheet, 1 x roll of Epson Paper, power cables, set-up guide, utility software and user manuals (on CD), RIP software (on DVD).
Packaging (WxHxD)
Printer 3300 x 1080 x 1130mm, 470Kg
CISS, MSS, Dryer & ATU 3213 x 1200 x 1100mm
320Kg R5000
Starter Ink & Media Pack 1500 x 500 x 1000mm, 50Kg
SYSTEM REQUIREMENTS
A Computer will be required for installation and operation of this printing system. The PC should have a minimum 2Ghz processor (3Ghz faster with separate GPU recommended), 8GB memory, a 250GB or larger HDD (1TB recommended), 1280x1024 or higher monitor, running 64bit Windows 7 or OS X/10.7 or greater. For optimum performance it is recommended that 1000Base-T Ethernet networking be employed. A network with external internet access will be required for installation, registration and software activation. Operation of Epson Cloud Solution PORT will require that the printer be connected to a network with internet access and the router configured for two-way data exchange.
CONFIGURATION OPTIONS
SCR5000L1YR Printer with 1Yr On-Site CoverPlus
SCR5000L3YR Printer with 3Yr On-Site CoverPlus
SCR5000L5YR Printer with 5Yr On-Site CoverPlus
ACCESSORIES & OPTIONS
C12C937271 Optional Media Spacer (enables operation with heat sensitive media)
1YWR5000L 1Yr CoverPlus On-Site Service Pack
2YWR5000L 2Yr CoverPlus On-Site Service Pack
SERVICE & SUPPORT
This printer is covered by a 30-day warranty that covers parts and labour (including the print head). It is supplied with additional CoverPlus that extends cover to a total of 1, 3 or 5 years. Customers who need 2 or 4 year cover should purchase an additional 1 year of CoverPlus. Customers who order their printer with 1 or 3 year CoverPlus may extend cover through the purchase of one or more CoverPlus Packs within 365 days of the original installation (total cover may not exceed 5 years).

Limitations apply to the provision of Warranty and CoverPlus. Support is only provided for product supplied through Epson Australia or Epson New Zealand. The facility is provided in conjunction with the Authorised Large Format Reseller through which the product is ordered and Epson’s network of Authorised Service partners. Service will be provided on-site at no charge for equipment located in major metropolitan areas with ready access. Regional locations and installations with difficult access may receive on-site service subject to the imposition of a travelling/access charge.

IMPORTANT NOTES
Epson Cloud Solution PORT is a secure cloud-based service that is used to facilitate the provision of support on this model. Agreement to the terms of supply and registration under the program is required to enable fulfilment of CoverPlus. During operation the printer must remain connected to a network with internet access via a router configured for two- way data transfer.

This model supports user-replacement of print heads. Operation requires Cloud Solution PORT and nomination of one or more staff members to perform the process. Staff should have a moderate level of technical skill and will be required to undertake training (this can generally be performed during the installation process). In the event that staff leave employment, replacements will need to be nominated and undertake training (this may attract additional charges).

Service may be restricted or limited if equipment is not installed in an appropriate environment, not appropriately maintained, is modified, used outside of specification &/or with non-Epson consumables. For further details on cover, terms and conditions please review the warranty terms listed on this web-site. If you have additional questions please contact Epson directly.
Usage Conditions
Epson products are designed and made to give highly reliable use and long life when used according to its specifications. With any system, product or device used in situations where human life may be involved or at risk, Epson advises that you should take all necessary steps to ensure the suitability of your Epson product for inclusion in your system, and recommends that you include fail-safe procedures and redundancy support or backup equipment in your system, to maintain the maximum safety margin and optimum system reliability. Examples include but are not limited to – do not interfere with any electrical components within the device, do not use items supplied with the product for purposes other than as intended by Epson (ie mains cords, inks, CDs, plastic wrapping) and do not make modifications to the product.
